23052-BE-XL FAG

23052-BE-XL FAG

23052-BE-XL FAG Có sẵn tại kho ATEC

Đầy đủ chứng từ CO,CQ do Schaeffler Group cấp.

Thay thế : 23052-BE FAG



Liên hệ để nhận được báo giá

Chi tiết sản phẩm

23052-BE-XL FAG Spherical roller bearing (X-life)

23052-BE-XL FAG

Weight and Dimensions

Inner (d) MM260

Outer (D) MM400

Width (B) MM104

Inner (d) Inch10.2362

Outer (D) Inch15.748

Width (B) Inch4.0945

Weight (kg)49.5

23052-BE-XL FAG

Product Properties

BoreC - Cylindrical Bore

Lubrication EnhancementW33 - Lubrication Groove and 3 Holes

SealNo Seal

Cage TypeS - Steel or Standard Cage

Radial Internal PlayCn Normal Internal Play

PrecisionStandard Precision

Heat StabilizationNo Heat Stabilization - Temperatures up to 120 °C

Vibrating Screen ExecutionNon Vibrating Screen Execution

23052-BE-XL FAG

Data from Schaeffler (medias)

Width (b) mm104

Radial Static Load Rating C0r (N)2600000

Radial Dynamic Load Rating Cr (N)1670000

Basic static load rating, radial (C 0r)"2600000.0000"

Limiting speed (n G)1850

Reference speed (n ϑr)1170

ECLASS number23-05-09-11

ECLASS2 number23-05-09-11

Medias descriptionSpherical roller bearings 230..-E1, main dimensions to DIN 635-2

23052-BE-XL FAG

Suffix description

BEMaximum Capacity Design

XLX-Life

Product description

The 23052-BE-XL FAG is a spherical roller bearing. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.

The 23052-BE-XL FAG is an X-life type bearing. X-life bearings provide better performance than normal spherical roller bearings due to a special internal construction. Contact surfaces, steel grade and rolling bodies are of a higher quality. X-life bearings combine a higher load capacity with a longer service life. The bearings generate less heat and allow for higher speeds. Finally, X-life bearings allow for longer maintenance intervals compared to normal spherical roller bearings.

23052-BE-XL FAG
