GE40-AW-A INA

The GE40-AW-A INA is an axial spherical plain bearing. Axial spherical plain bearings are two-piece plain bearings. They have no rolling elements, but consist of a shaft washer and a housing washer. The shaft washer has a convex surface. The housing washer has a concave inner surface. This construction gives spherical plain bearings their high load carrying capacity and capacity to accommodate misalignment.

The GE40-AW-A INA has a steel-on-PTFE sliding contact which makes it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.

Brand
INA
Item Number
GE40-AW-A INA
Manufacturer Part Number
0066516740000
Also known as
GX40F
EAN
4012802532517
Category
Spherical Plain Bearing

nner (d) MM
40
Outer (D) MM
105
Width (B) MM
32

Product Properties
Seal
No Seal
Contact Material
Steel on PTFE
Data from Schaeffler (medias)
Outside diameter  bearing (D) mm
105
Height (T)  mm
32
Width inner ring (B) mm
27
Axial Static Load Rating C0a (N)
1870000
Axial Dynamic Load Rating Ca (N)
112000

Medias description
Axial spherical plain bearing, maintenance-free, DIN ISO 12240-3, shaft location washer curved surface with hard chromium coating, open design

Suffix description
AW
Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))
A
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
