SL045030-PP-2NR-INA

SL045030-PP-2NR INA

Double-row full-complement cylindrical roller bearing

Weight and Dimensions

Inner (d) MM150

Outer (D) MM225

Width (B) MM100

Inner (d) Inch5.9055

Outer (D) Inch8.8583

Width (B) Inch3.937

Weight (kg)13.5

Product Properties

BoreC - Cylindrical Bore

Seal2L - LS-seal at Both Sides

Cage TypeFC - Full Complement, No Cage

External Modification2R - 2 Snap Rings in O.D.

Radial Internal PlayCn Normal Internal Play

PrecisionStandard Precision

Heat StabilizationNo Heat Stabilization - Temperatures up to 120 °C

Suffix description

PPLip Seals On Both Sides Of The Bearing

2NRSupplied With Two Loose-Packed Retaining Rings WRE

Product description

The SL045030-PP-2NR INA is a full-complement double-row cylindrical roller bearing. This bearing has a particularly high radial load capacity. The design consists of a solid inner and outer ring with a double row of cylindrical rollers. These rolling elements are guided between flanges. Since there is no cage, a maximum number of rollers can be used. This type of bearing is therefore suitable for very heavy loads where lower rotational speeds are involved.
