KB40-PP INA Có sẵn tại kho ATEC
Đầy đủ chứng từ CO,CQ do Schaeffler Group cấp.
Thay thế:
LAA40X62X80.2RS FAG
LBCR40-2LS SKF
Linear ball bearings (heavy range) KB..PP, sealed on all sides
Inner (d) MM40
Outer (D) MM62
Width (B) MM80
Inner (d) Inch1.5748
Outer (D) Inch2.4409
Width (B) Inch3.1496
Weight (kg) 0.686
Seal2L - LS-seal at Both Sides
Length (L) mm80
Load capacity dyn. (C min)6000
Load capacity stat. (C 0 min)4400
Load capacity stat. (C 0 max)5600
ECLASS number23-30-03-01
ECLASS2 number23-30-03-01
Medias descriptionLinear ball bearings KB..-PP, machined range, sealed on all sides, corrosion-resistant design possible
PPLip Seal On Both Sides Of Bearing
The KB40-PP INA is a ball bushing or linear ball bearing from INA's machined range. These ball bushings are particularly durable and they have a high running accuracy. The balls run with great precision thanks to a special spring washer. The result is low and even displacement resistance, also under severe operating conditions and regardless of the installed position.
The closed design makes this bearing suitable for use on unsupported shafts. The outer ring accommodates a plastic cage and balls. When the ball bushing is in motion, the rolling elements follow a trajectory returning through openings in the outer ring.
